Description
The MAG is a bolt-on electromagnetic lock for powered access control. Available in 2 versions; the MAG3000 has up to 660 lbs. and the MAG6000 which has up to 1320 lbs. of pull force resistance. The aluminium powder coated housing with integrated design handles gives your access control gate that extra elegant touch. Stop losing precious time with welding boxes; drilling just 7 holes does the job – our patented Quick-Fix bolts help you install quickly and easily. A two-layer, protective coating guarantees that our electromagnetic locks are ready for years of worry-free use in the outside elements
- Guaranteed holding force tested on every magnetic lock
- 500h salt spray resistant! SGS certified (ISO 9227)
- Tested according to ISO 9227
- Special two-layer protective coating developed for outdoor use
- Powder coated aluminium housing
- Anti-residual magnetism kick-off system
- Raised edge on the magnet housing makes it impossible to put a crowbar between the magnet and the armature plate
- Fail open
- Fast and easy fixing by means of 5 holes with Quick-Fix
- Voltage: 12V / 24V DC
Specifications
weight: 4.11 kg
length: 217.0mm
width: 98.0mm
depth: 68.0mm
Product Documentation
LOCMAG Product Dimensions
